Main Table Dimensions

Overview

Below is a dimensional diagram of the main cast iron table for Harvey Alpha Series table saws. All measurements are in millimeters (mm).

Main Table — Dimensional Diagram

All measurements in millimeters (mm)

Harvey Alpha Series — Main Cast Iron Table Dimensional Drawing (mm)

For questions about main table dimensions or compatibility, please contact our support team.
