Alpha HW615/Ambassador C14 Band Saws: Leveling Feet Thread Specifications

Created by Gabriel Izzo, Modified on Wed, 20 May at 7:50 PM by Gabriel Izzo

Alpha HW615 / Ambassador C14 Band Saws · Specifications
Leveling Feet Thread Specifications
Applicable Models
Alpha HW615
Alpha HW615 Pro
Ambassador C14
Ambassador C14 Pro
Leveling Feet — Part #132 Anchor Bolt
SpecificationValue
Thread TypeM12
Thread Pitch1.75
Thread Length60 mm
Full SpecificationM12–1.75 × 60mm
When replacing or sourcing alternate leveling feet or anchor bolts, ensure replacements match the above specifications for proper fit and stability.
Part #132 — Anchor Bolt M12×60 with Thread Checker
Part 132 anchor bolt M12x60 shown with thread checker
i

For help sourcing replacement leveling feet or anchor bolts, please contact our support team.
