Compass ST-1500 Sliding Table: SawStop PCS Mounting

Created by Gabriel Izzo, Modified on Mon, 18 May at 8:28 PM by Gabriel Izzo

Compass ST-1500 Sliding Table · Mounting

SawStop PCS Mounting

Applicable Models

Compass ST-1500 Sliding Table

SawStop PCS 27"

✓

The ST-1500 is compatible with SawStop PCS 27" models and comes with dedicated mounting hardware, as well as pre-drilled holes for both standard and flush mounting.

For SawStop ICS table saws, please refer to the dedicated article for ICS mounting options:

Compass ST-1500 Sliding Table: SawStop ICS Mounting ↗

Included Hardware — PCS Mounting

For PCS models, use the following included hardware and mounting holes (standard or flush mounted):

Fig. 1 — PCS Mounting Hardware

Pre-Drilled Hole Pattern — SawStop PCS 27"

Fig. 2 — Pre-Drilled Holes for SawStop PCS 27" Table Saws

ST-1500 pre-drilled hole pattern diagram for SawStop PCS 27 inch table saws

Instruction Manual

PDF Compass ST-1500 Sliding Table Instruction Manual ↗

Need further assistance with mounting or alignment? Please contact our support team.
